Rent a Bobcat E32 Mini Excavator - Bobcat Rental in Michigan

Rental Rates

The E32 features unmatched power and a narrow stance.

• Powerful performance and maneuverability
• Conventional tail swing
• Ideal for restrictions like doors and gates
• Various arm options

Specs

Key Specs

Specs	E32	E32 - Long Arm	E32 - Extendable Arm
Operating Weight	7,403 lb	8,269 lb	8,497 lb
Bucket Digging Force	7,284 lbf	7,284 lbf	7,284 lbf
Maximum Reach at Ground Level	194.5 in	205.9 in	225.3 in
Width	61.8 in	61.8 in	61.8 in
Tail Swing Type	Conventional	Conventional	Conventional

Engine

Specs	E32	E32 - Long Arm	E32 - Extendable Arm
Emissions Tier	Tier 4	Tier 4	Tier 4
Engine Fuel	Diesel	Diesel	Diesel
Maximum Governed RPM	2,450 RPM	2,450 RPM	2,450 RPM
Turbocharged Engine	No	No	No

Performance

Specs	E32	E32 - Long Arm	E32 - Extendable Arm
Operating Weight	7,403 lb	8,269 lb	8,497 lb
Weight Class	3.4 Ton	3.8 Ton	3.9 Ton
Travel Speed - High	2.9 mph	2.9 mph	2.9 mph
Travel Speed - Low	1.6 mph	1.6 mph	1.6 mph
Arm Digging Force	4,690 lbf	4,074 lbf	4,592 lbf
Bucket Digging Force	7,284 lbf	7,284 lbf	7,284 lbf
Lift Radius	118 in	118 in	118 in
Boom Swing - Left	75°	75°	75°
Boom Swing - Right	55°	55°	55°
Maximum Dig Depth	121.2 in	133 in	153.2 in
Max Dump Height	137.2 in	144.3 in	154.5 in
Maximum Reach at Ground Level	194.5 in	205.9 in	225.3 in

Capacities

Specs	E32	E32 - Long Arm	E32 - Extendable Arm
Fuel Tank	13.7 gal	13.7 gal	13.7 gal

Hydraulic System

Specs	E32	E32 - Long Arm	E32 - Extendable Arm
Auxiliary Standard Flow	16.9 gal/min	16.9 gal/min	16.9 gal/min
Auxiliary Pressure	2,987 psi	2,987 psi	2,987 psi

Dimensions

Specs	E32	E32 - Long Arm	E32 - Extendable Arm
Length	183.7 in	183.7 in	187.6 in
Overall Length in Travel Position	183.7 in	183.7 in	183.7 in
Width	61.8 in	61.8 in	61.8 in
Height	96.2 in	96.2 in	96.2 in
