Take on more complex tasks with the precise performance, comfort and versatility of the E42 compact excavator.

• Redesigned Bobcat engine
• Multiple arm configurations
• Low-effort joysticks
• Conventional tail swing

Specs

Key Specs

Specs	E42	E42 - Extendable Arm	E42 - Long Arm
Operating Weight	9,830 lb	10,666 lb	10,425 lb
Bucket Digging Force	9,601 lbf	9,601 lbf	9,601 lbf
Maximum Reach at Ground Level	207.1 in	229.2 in	218.4 in
Width	72.8 in	72.8 in	72.8 in
Tail Swing Type	Conventional	Conventional	Conventional

Engine

Specs	E42	E42 - Extendable Arm	E42 - Long Arm
Emissions Tier	Tier 4	Tier 4	Tier 4
Engine Fuel	Diesel	Diesel	Diesel
Maximum Governed RPM	2,200 RPM	2,200 RPM	2,200 RPM
Horsepower	42 hp	42 hp	42 hp
Turbocharged Engine	Yes	Yes	Yes

Performance

Specs	E42	E42 - Extendable Arm	E42 - Long Arm
Operating Weight	9,830 lb	10,666 lb	10,425 lb
Weight Class	4.5 Ton	4.8 Ton	4.7 Ton
Travel Speed - High	3.3 mph	3.3 mph	3.3 mph
Travel Speed - Low	1.6 mph	1.6 mph	1.6 mph
Arm Digging Force	5,820 lbf	5,852 lbf	5,803 lbf
Bucket Digging Force	9,601 lbf	9,601 lbf	9,601 lbf
Lift Radius	118 in	118 in	118 in
Boom Swing - Left	75°	75°	75°
Boom Swing - Right	50°	50°	50°
Maximum Dig Depth	124.5 in	148.8 in	136.8 in
Max Dump Height	150.6 in	164.4 in	158.4 in
Maximum Reach at Ground Level	207.1 in	229.2 in	218.4 in

Capacities

Specs	E42	E42 - Extendable Arm	E42 - Long Arm
Fuel Tank	19 gal	19 gal	19 gal

Hydraulic System

Specs	E42	E42 - Extendable Arm	E42 - Long Arm
Auxiliary Standard Flow	20 gal/min	20 gal/min	20 gal/min
Auxiliary Pressure	3,045 psi	3,045 psi	3,045 psi

Dimensions

Specs	E42	E42 - Extendable Arm	E42 - Long Arm
Length	200.5 in	201.3 in	201.7 in
Overall Length in Travel Position	200.5 in	201.3 in	201.7 in
Width	72.8 in	72.8 in	72.8 in
Height	99.1 in	99.1 in	99.1 in
