Bobcat L28 - Rental

Rent a Bobcat L28 Articulating Loader - Bobcat Rental in Michigan

The L28 Bobcat® small articulated loader delivers big performance and heavy lifting in a small package.

  • Easily works inside fenced-in landscapes, pens, backyards and more.
  • Impressive lifting capacity and telescoping lift arm
  • Tight-turning articulation joint
  • Power Bob-Tach System
Specs

Key Specs

Horsepower 24.8 hp
Rated Operating Capacity Straight (ISO) 1,534 lb
Rated Operating Capacity Articulated 1,222 lb
Operating Weight 4,195 lb
Auxiliary Standard Flow 12.1 gal/min
Width (Over Tires) 46.5 in
Max Reach 30.9 in
Height to Bucket Hinge Pin Extended 104.3 in

Engine

Emissions Tier (EPA) Tier 4
Engine Cooling Liquid
Engine Fuel Diesel
Horsepower 24.8 hp
Turbocharged Engine

No

Performance

Rated Operating Capacity Straight (ISO) 1,534 lb
Rated Operating Capacity Articulated (ISO) 1,222 lb
ROC with Counterweight - Straight 1,952 lb
ROC with Counterweight - Articulated 1,475 lb
Tipping Load - Straight 3,068 lb
Tipping Load - Articulated 2,444 lb
Operating Weight 4,195 lb
Travel Speed 8.3 mph

Capacities

Fuel Tank 9.6 gal

Hydraulic System

Auxiliary Std Flow 12.1 gal/min
System Relief @ Quick Couplers 2,900 psi

Dimension

Length 122.4 in
Length without Attachment 93.2 in
Length with Standard Bucket
122.4 in
Width (Over Tires) 46.5 in
Width (With Bucket) 50 in
Height with Operator Cab 78.1 in
Height to Bucket Hinge Pin Extended 104.3 in
Height to Bucket Hinge Pin Retracted 85.4 in
Max Reach 30.9 in
Turning Radius Inside 78.2 in
Turning Radius Outside 100.9 in
Wheelbase 47.2 in
Articulation Angle 43°
Dump Angle @ Maximum Height 40°
Ground Clearance 5.5 in
Rollback Angle 32°
Tire Size 23X10.5-12 8 PLY
Wheel Tread 36.4 in
    $44.80

    Original: $128.00

    -65%
    Bobcat L28 - Rental

    $128.00

    $44.80

    Product Information

    Shipping & Returns

    Description

    Rent a Bobcat L28 Articulating Loader - Bobcat Rental in Michigan

    The L28 Bobcat® small articulated loader delivers big performance and heavy lifting in a small package.

    • Easily works inside fenced-in landscapes, pens, backyards and more.
    • Impressive lifting capacity and telescoping lift arm
    • Tight-turning articulation joint
    • Power Bob-Tach System
    Specs

    Key Specs

    Horsepower 24.8 hp
    Rated Operating Capacity Straight (ISO) 1,534 lb
    Rated Operating Capacity Articulated 1,222 lb
    Operating Weight 4,195 lb
    Auxiliary Standard Flow 12.1 gal/min
    Width (Over Tires) 46.5 in
    Max Reach 30.9 in
    Height to Bucket Hinge Pin Extended 104.3 in

    Engine

    Emissions Tier (EPA) Tier 4
    Engine Cooling Liquid
    Engine Fuel Diesel
    Horsepower 24.8 hp
    Turbocharged Engine

    No

    Performance

    Rated Operating Capacity Straight (ISO) 1,534 lb
    Rated Operating Capacity Articulated (ISO) 1,222 lb
    ROC with Counterweight - Straight 1,952 lb
    ROC with Counterweight - Articulated 1,475 lb
    Tipping Load - Straight 3,068 lb
    Tipping Load - Articulated 2,444 lb
    Operating Weight 4,195 lb
    Travel Speed 8.3 mph

    Capacities

    Fuel Tank 9.6 gal

    Hydraulic System

    Auxiliary Std Flow 12.1 gal/min
    System Relief @ Quick Couplers 2,900 psi

    Dimension

    Length 122.4 in
    Length without Attachment 93.2 in
    Length with Standard Bucket
    122.4 in
    Width (Over Tires) 46.5 in
    Width (With Bucket) 50 in
    Height with Operator Cab 78.1 in
    Height to Bucket Hinge Pin Extended 104.3 in
    Height to Bucket Hinge Pin Retracted 85.4 in
    Max Reach 30.9 in
    Turning Radius Inside 78.2 in
    Turning Radius Outside 100.9 in
    Wheelbase 47.2 in
    Articulation Angle 43°
    Dump Angle @ Maximum Height 40°
    Ground Clearance 5.5 in
    Rollback Angle 32°
    Tire Size 23X10.5-12 8 PLY
    Wheel Tread 36.4 in
