Bobcat S770 Series - Rental

Take on challenging jobs with confidence by renting the powerful Bobcat S770 skid-steer loader. Designed for both performance and comfort, this machine features a Tier 4 diesel engine that delivers 92 horsepower, ensuring reliable power even in tough conditions. The rugged build supports a rated operating capacity of 3,350 lb, so handling heavy materials is effortless. With a travel speed ranging from 7.1 mph up to 12.3 mph (with two-speed option), you can move around the jobsite quickly and efficiently. Thanks to the ample 23.9-gallon fuel tank, you’ll spend more time working and less time refueling. Read on for rental rates and comprehensive specs to see how the Bobcat S770 can support your next project.

Rental Rates

Daily	Weekly	Monthly
$400	$1,200	Call for Pricing Plans

Description

The Bobcat® S770 skid-steer loader is loaded with performance and comfort features that can’t be matched by other machines in the same size class. Whether you’re moving heavy material or tackling construction tasks, the S770’s reliable power, sturdy design, and maneuverability can help you get the job done efficiently.

Specs

Engine

Emissions Tier (EPA)	Tier 4
Engine Cooling	Liquid
Engine Fuel	Diesel
Horsepower	92
Turbocharged Engine	Yes

Performance

Rated Operating Capacity (ISO)	3,350 lb
Tipping Load	6,700 lb
Operating Weight	9,314 lb
Travel Speed	7.1 mph
Travel Speed (2 - Speed Option)	12.3 mph

Capacities

Fuel Tank

23.9 gal

Hydraulic System

Auxiliary Std Flow	23 gal/min
Auxiliary High Flow	36.6 gal/min

Dimension

Length	141.6 in
Length Without Attachment	114.3 in
Length With Standard Bucket	141.6 in
Width	72.1 in
Width (With Bucket)	74 in
Height	81.3 in
Height With Operator Cab	81.3 in
Height to Bucket Hinge Pin	131.4 in
Reach @ Maximum Height	33.6 in
Turning Radius	85.8 in
Wheelbase	48.3 in
