Bobcat T64 Series - Rental

Experience a versatile solution for your projects with the Bobcat T64 Series, a compact track loader designed to excel in tight spaces and a wide range of applications. Its vertical-lift-path design offers increased reach and lift height, making it effective for loading materials and working at elevated positions. With a powerful 68-horsepower diesel engine, you can rely on strong pushing force and efficient performance. An ergonomic operator’s cab, intuitive controls, and impressive stability further enhance productivity on any jobsite. Whether you need reliable handling for heavy-duty tasks or smooth maneuverability for detailed work, the T64 Series combines power, precision, and comfort in one robust package.

Description

The vertical-lift-path Bobcat® T64 compact track loader delivers leading performance for maximum lifting and pushing power.

Specs

Engine

Emissions Tier (EPA)	Tier 4
Engine Cooling	Liquid
Engine Fuel	Diesel
Horsepower	68
Turbocharged Engine	Yes

Performance

Rated Operating Capacity (ISO)	2,300 lb
Operating Capacity (50% of Tip)	3,286 lb
Tipping Load	6,571 lb
Operating Weight	8,727 lb
Travel Speed	7.2 mph
Travel Speed (2 - Speed Option)	10.2 mph
Ground Pressure (Rubber)	5.7 psi

Capacities

Fuel Tank

28.3 gal

Hydraulic System

System Relief @ Quick Couplers	3,500 psi
Auxiliary Std Flow	17.6 gal/min
Auxiliary High Flow	26.9 gal/min

Dimension

Length	134.9 in
Length Without Attachment	107 in
Length With Standard Bucket	134.9 in
Width	67 in
Width (With Bucket)	68 in
Height	80.5 in
Height With Operator Cab	80.5 in
Height to Bucket Hinge Pin	120 in
Reach @ Maximum Height	36.7 in
Turning Radius	81.5 in
Length of Track on Ground	54.3 in
Track Width	12.6 in
