Bobcat T770 Compact Track Loader

Experience legendary performance with the T770, a top-selling compact track loader. Engineered to protect your uptime, this versatile machine delivers the performance you need to make light work of big projects, with an impressive rated operating capacity, powerful breakout forces and fast cycle times.

• Non-DPF Bobcat engine
• Durable undercarriage
• High-performance cooling
• Operator-friendly controls

Specs

Configuration

Engine



Emissions Tier (EPA)	Tier 4
Engine Cooling	Liquid
Engine Fuel	Diesel
Horsepower	92 hp
Turbocharged Engine	Optional

Performance

Rated Operating Capacity (ISO)	3,475 lb
Operating Capacity (50% of Tip)	4,960 lb
Tipping Load	9,929 lb
Operating Weight	10,515 lb
Travel Speed	6 mph
Travel Speed (2 - Speed Option)	9.3 mph
Ground Pressure (Rubber)	4.2 psi

Capacities

Fuel Tank

44.4 gal

Hydraulic System

System Relief @ Quick Couplers	3,500 psi
Auxiliary Std Flow	23 gal/min
Auxiliary High Flow	36.6 gal.min

Dimension

Length	141.6 in
Length Without Attachment	114.3 in
Length With Standard Bucket	141.6 in
Width	78 in
Width (With Bucket)	80 in
Height	81.3 in
Height With Operator Cab	81.3 in
Height to Bucket Hinge Pin	132 in
Reach @ Maximum Height	33.6 in
Turning Radius	88 in
Length of Track on Ground	63.7 in
Track Width	17.7 in
